Finally, Pulp Fiction

Looking good.
So you have a playfield protector and scoop trim.
Do you have links for them, or did you make the scoop trim yourself?
Ta

Sertx said:
Looking good.
So you have a playfield protector and scoop trim.
Do you have links for them, or did you make the scoop trim yourself?
Ta
Click to expand...

Playfield Protectors

Playfield Protectors - Full Protection for Your Pinball Machine... Established 2013
playfield-protectors.com playfield-protectors.com
SeikoKid said:
yes to both - After all the pinside posts on playfield condition for me it was a no brainer - Modification needed on protector where magnet is

Magnet burn widely reported / once done raise magnet inline with protector
Click to expand...

Issues ive had

Trough ejector solenoid rubber stopper fell out, confused me for a bit as getting failed ball eject, then found it floating in the cabinet.

Pawn shop ball hold solenoid had sleeve mounted wrong way round in coil. Again caused confusion and relentless waits when balls would not move from subway trough

Magnet switch was way off and needed adjusting, kept hitting it and nothing happened

All pop bumpers sensitivity was poor, still struggling with the top right.

Briefcase non return bar 3 out of 5 times prevents ball from entering VUK

Flipper set up imo poor and sloppy, wear on rubbers at end of bat was worse than I had with TNA and happened very quickly. Problem sorted by fitting precision bushes and stern clamp bars. Not had any wear since - photo shows wear on rubber, ive rotated them round so its at the back now

No sure the playfield protector I had fitted is suited to this game. Ive had lots of airballs from the 2 slings, lowered the plastic by removing the washers which helped, get it also off the back of the pawn shop. Not so much now, but it would fly from the right sling and dimple the left mirror blade, same with the left sling it would end up in the shooter lane,

I think the 2mm rise in height messes up the physics of the way the ball plays. But given the recorded issues with playfield chipping I felt at the time it was important, HOWEVER, now Ive made hole protectors I don't see the need for the playfield protector. As ive paid for it Ill run it a while longer but soon I reckon it will be coming off



SeikoKid

For Sale Thread 'PF Hole protectors'

£50 plus postage

Not needed in the centre saucer

Idea is to protect the back edge of the hole from
the ball slamming into it

Maybe the right one isn’t needed as much but we all love a set

Colour options. Red or Black

Damage shown without

Includes Mylar set for both VUK areas. Shooter Lane and Magnet. ( magnet already fitted , so its a spare or double up )

Sorry, had to increase price slightly due to briefcase mod, now also Mylar ( Vinyl ) in set

  • Like

I really really enjoy this game, as with them all now they need a bit o tweaking and nothing surprises me now after spending stupid amounts on a brand new pinball game from anyone ( except for my GZ - That's never had an issue or needed tweaking )


Attachments

  • IMG_1029.webp
    103.6 KB · Views: 38
  • IMG_1352.webp
    62.7 KB · Views: 37
  • IMG_1355.webp
    73.2 KB · Views: 38
Thanks for the info. Out of interest where or how did you get your Pulp Fiction? I thought only the odd one or two had made it over here until the big shipment arrives?

Last edited:
Useful info there @SeikoKid BTW protectors turned up the other day, look good.
Bit of a shame so many adjustments needed, was your game from the UK bound batch that got air shipped?

Was hoping with the UK games so late into the run most issues would have been sorted by now, a few tweaks isn't a showstopper, but still.....

I'm torn on the playfield protector, I do prefer the way games play without them, but have on on Mando, with no real issues, wonder if a combination of raising the ball in relation to the rubbers and the extra 'glide' contributes to more air balls, possibly worth trying the washers you removed under the posts??? thinking that would move the rubber slightly above the centre of the ball.

Sako-TRG said:
Those protectors, easy enough to put on?
Kinda like the idea of the overhanging lip.
Click to expand...
Yes, just requires removal of the 2 VUKs which have 3 screws and 2 screws
The topside is a couple nuts and screws

All 3 are push fit. Just very tight tolerance, you prob don’t need the roll scene but it’s a set so why not?
The switch extender is there because it changes the gap set and don’t want to bend the switch in case folk didn’t want it anymore or chose to remove etc etc

But i’m here to ask and can vid call you through it if you need help

I had already started to get the edge damage on the breifcase VUK less than 30/40 games and I think Neil has too so , ultimately it’s everyone’s choice

I’ve been thinking about this since @SeikoKid mentioned the playfield protector to me, but decided not to spend the money. In the end, I think I agree with what you’ve said above, some preventative maintenance is a good idea, but the equivalent of a sofa covered in plastic isn’t for me. I also worry that the protector its self could slide back and forth against the clear coat and slowly but surely dull the finish.

That said, I’m defo going to grab a set of protectors and maybe I need some Mylar wherever this place where the ball drops is.

Marvello said:
Prevention is better than cure and all that, but I don't want too get hung up on worrying about wear and tear. I'm just going to play mine and expect it will show signs of wear like any/most Pinball machines do.

I don't want it to be like Grandma's sofa.
Click to expand...
For £35 though against a £8k toy ….

Oh yes totally, as I mentioned it’s something i’ve been able to prove unnecessary but at the time my inexperience felt it was a good idea
So tempted to whip it off but relishing the perfect surface underneath

It’s gonna be a bit like opening a jar of coffee , where you run your nail around the edge of the tin foil cover and take it off and a real satisfying manor

Last edited:
Yeah I get what your saying about nannas sofa, really depends on the amount of play your expecting the game to see, probably OTT for home use, but can always peel it off.
Really don't wanna see scoop wear in a few weeks time tho.

kev a said:
Yeah I get what your saying about nannas sofa, really depends on the amount of play your expecting the game to see, probably OTT for home use, but can always peel it off.
Really don't wanna see scoop wear in a few weeks time tho.
Click to expand...
That’s the talk of many across the USA about this build
Hopefully I’ve helped to prevent or delay it, if i’m wrong at least I tried and for me atm it’s working

SeikoKid said:
That’s the talk of many across the USA about this build
Hopefully I’ve helped to prevent or delay it, if i’m wrong at least I tried and for me atm it’s working
Click to expand...
Sure seems like they will, I mean its a hard metal ball vs wood and paint, only going to be one winner, so having something sacrificial to take the impact makes sense.
