Terminator 2 flipper problem

Hey guys, just an update.

Capacitors arrived and I've finally swapped them out, spotted a burnt out trace on the board when I removed it so fixed that. I was just about to reinstall the board and spotted something else blown, It's connected to the heatsink in location U1. Some of the details are missing off it and I can't find any info in the manual. Very happy I spotted it before plugging it back in but feels like another step backwards.


Attachments

  • PXL_20241109_182934947.webp
    79.9 KB · Views: 22
  • PXL_20241109_182934947.webp
    79.9 KB · Views: 22
Last edited:
Thanks Paul, as they say, even a broken clock is right twice a day 😅

I assume it needs thermal paste as that's one of the things listed in the manual at U1
